Dual Inline Over Centre Valve
Pilot Ratio: 4.25/1
01 White Spring Range 20 – 200 Bar, Factory Setting 100 Bar
02 Black Spring Range 50 – 350 Bar, Factory Setting 280 Bar
Dual Overcentre Valve
Pilot Ratio: 4.25/1
01 White Spring Range 20 – 200 Bar, Factory Setting 100 Bar
02 Black Spring Range 50 – 350 Bar, Factory Setting 280 Bar
Single Inline Over centre Valve
Pilot Ratio: 4.25/1
01 White Spring Range 20 – 200 Bar, Factory Setting 100 Bar
02 Black Spring Range 50 – 350 Bar, Factory Setting 280 Bar
Single Overcentre Valve With External Pilot
Pilot Ratio: 4.25/1
01 White Spring Range 20 – 200 Bar, Factory Setting 100 Bar
02 Black Spring Range 50 – 350 Bar, Factory Setting 280 Bar
Direct Acting Cartridge
Pressure Range:
01 White Spring Range 20 – 100 Bar, Factory Setting 80 Bar
02 Yellow Spring Range 40 – 250 Bar, Factory Setting 180 Bar
03 Black Spring Range 60 – 350 Bar, Factory Setting 250 Bar
