ECO Very Efficient Compact Cooler For Mobile Application
12v Or 24v DC Motor Long Life
Maximum Static Pressure/Dynamic Pressure: 21/14 Bar
Long Life Power Coating With Zinc Phosphate Pre Treatment
Low Pressure Drop Aluminium Cores
Available Options:
— Temperature Switch
— Dust/Stone Guard
— Internal/External Bypass
| Part Number | DESCRIPTION | CONNECTION | ACOUSTIC PRESSURE | CURRENT | WEIGHT |
|---|---|---|---|---|---|
| 801004250 | ECO 04-12V-000 | G1 | 70 dB(A) | 10 AMP | 5.5 KG |
| 801004260 | ECO 04-24V-000 | G1 | 70 dB(A) | 6 AMP | 5.5 KG |
| 801007250 | ECO 07-12V-000 | G1 | 70 dB(A) | 20 AMP | 8.0 KG |
| CBFVPN12MF | ECO 07-24V-000 | G1 | 70 dB(A) | 11 AMP | 8.0 KG |
| Brand |
|---|
Available in over 30 standard model variants. Made with high performance aluminium cooling elements and heavy duty zinc seal powder coated casings for excellent appearance and durability.
Max. Static Pressure: 21 Bar
Max. Dynamic Pressure: 14 Bar
Temperature Shock Tested With 104ºC Steam | 13ºC Water
Low Pressure Drop Aluminium Cores
Temperature Switch Port
By-Pass Option Available
Air Cooled Exchangers With Aluminium Cooling Elements
