Description
LDA MODEL
| PART NUMBER | HYDRAULIC MOTOR SHAFT TYPE | SLEEVE PART NUMBER |
|---|---|---|
| 64/125101 ^ | Spline 9T 5/8” OD 16/32 DP | 64/03/20001 |
| 64/125102 ^ | Spline 11T 3/4” OD 16/32 DP | 64/03/20002 |
| 64/125112 | Round 0.625” OD 0.156” Keyway | |
| 64/125113 ^ | Round 0.750” OD 0.187” Keyway | 64/03/20013 |
| 64/125114 | Round 0.875” OD 0.250” Keyway | |
| 64/125115 * | Round 1.000” OD 0.25” Keyway | |
| 64/125126 # | Round 25mm OD 8mm Keyway |
^ Basic Model 64/125115 Fitted With Sleeve.
# For SAM HYDRAULIK-BG…N With Shaft Type C25
* Directly Replaces Model 03-35-00043.
