Sizes: 10.2cc/rev to 40.6cc/rev
Shaft: ⅝’’ 9 spline up to 1½’’ gear set
⅞’’13 spline
⅞’’ parallel keyed
Mount: SAE A 2 bolt
SAE B 2 bolt
| CODE | GEAR WIDTH | CC/REV | MAX. PRESSURE | MAX. Speed |
|---|---|---|---|---|
| 05 | 1/2″ | 10.2 | 3500 PSI | 3000 RPM |
| 07 | 3/4″ | 15.2 | 3500 PSI | 3000 RPM |
| 10 | 1.0″ | 20.3 | 3500 PSI | 3000 RPM |
| 12 | 1 1/4″ | 25.4 | 3500 PSI | 3000 RPM |
| 15 | 1 1/2″ | 30.5 | 3250 PSI | 3000 RPM |
| 17 | 1 3/4″ | 35.6 | 2750 PSI | 3000 RPM |
| 20 | 2.0″ | 40.6 | 2500 PSI | 3000 RPM |
| PART NUMBER | ACCESSORIES – DESCRIPTION |
|---|---|
| M315SK1 | M315 Single Motor Seal Kit |
| M315RK1 | Repair Kit – Inc. Bushes & Thrust Plate |
| Brand |
|---|
Shaft: SAE C 1 ¼” 14T Spline | SAE C 1 ¼” Parallel Keyed
SAE D 1 3/4” 13T Spline
Mount: SAE B 4 Bolt
SAE C 2 & 4 Bolt | SAE D 4 Bolt
Shaft: SAE A ⅝” 9T Spline
SAE B ⅞” 13T Spline
SAE B ⅞” Parallel Keyed
SAE BB 1” Parallel Keyed
Mount: SAE A 2 Bolt | SAE B 2 & 4 Bolt
6 Bolt Round Chelsea 4 Bolt
Shaft: SAE B ⅞” 13T Spline
SAE C 1 ¼” 14T Spline | SAE C 1 ¼” Parallel Keyed
Mount: SAE B 2 & 4 Bolt | SAE C 2 & 4 Bolt
6 Bolt Round 2.625” Spigot
