Maximum Displacement: 501.5 cc/rev
Maximum Flow Rate: 328 GPM/901 LPM
Operating Pressure: 350 Bar/5000 PSI
Side/Rear/Opposing Ports, Mount & Shaft: SAE
Flange, Straight Threaded Port Types
| MODEL SERIES | CC/REV | Max. Cont. pressure (PSI) | Max. Speed (RPM) | Flow @1500 RPM | Case pressure cont. |
|---|---|---|---|---|---|
| M6 | 98.3 | 5000 | 3000 | 148 LPM | 75 PSI |
| M7 | 118.8 | 5000 | 3000 | 178 LPM | 75 PSI |
| M8 | 131.1 | 5000 | 2100 | 197 LPM | 75 PSI |
| M11 | 180.3 | 5000 | 2400 | 269 LPM | 75 PSI |
| M14 | 229.5 | 5000 | 2400 | 344 LPM | 75 PSI |
| M24 | 403.2 | 5000 | 2100 | 606 LPM | 75 PSI |
| M30 | 501.5 | 5000 | 1800 | 753 LPM | 75 PSI |
| Brand |
|---|
F11-F12 Hydraulic Motor PDF
F11-F12 Saw Motor PDF
Max. Cont. Speed.: 7300 RPM
Max. Oil Flow: 363 LPM
Max. Operating Speed: 14000 RPM
F11-F12 Hydraulic Motor PDF
F11-F12 Saw Motor PDF
Max. Cont. Speed: 12800 RPM
Max. Oil Flow: 363 LPM
Max. Operating Speed: 14000 RPM
