Shaft: SAE A ⅝” 9T Spline
SAE B ⅞” 13T Spline
SAE B ⅞” Parallel Keyed
SAE BB 1” Parallel Keyed
Mount: SAE A 2 Bolt
SAE B 2 & 4 Bolt
6 Bolt Round Chelsea 4 Bolt
| GEAR WIDTH | CC/REV | MAX PRESSURE | MAX RPM |
|---|---|---|---|
| 1/2″ | 16.1 | 3000 | 2400 |
| 3/4″ | 24.2 | 3000 | 2400 |
| 1.0″ | 32.3 | 3000 | 2400 |
| 1 1/4″ | 40.4 | 3000 | 2400 |
| 1 1/2″ | 48.5 | 3000 | 2400 |
| 1 3/4″ | 56.5 | 2500 | 2400 |
| 2.0″ | 64.6 | 2500 | 2400 |
| PART NUMBER | ACCESSORIES – DESCRIPTION |
|---|---|
| P20SK1 | P020 Single Pump Seal Kit |
| P20SK2 | P020 Tandem Pump Seal Kit |
| P20RK1 | Repair Kit – Inc. Bearing & Thrust Plate |
| 3910381040 | Outboard Bearing |
| ADD ONS |
|---|
| C Shaft |
| Transmission Seal |
| Viton Shaft & Section Seals |
| Piggy Back Port End Cover |
| Brand |
|---|
Shaft: SAE A ⅝” 9T Spline
SAE B ⅞” 13T Spline
SAE B ⅞” Parallel Keyed
SAE BB 1” Parallel Keyed
Mount: SAE A 2 Bolt
SAE B 2 & 4 Bolt
SAE C 4 Bolt
6 Bolt Round 2.625 Spigot
Shaft: SAE B ⅞” 13T Spline
SAE BB 1” 15T Spline
SAE BB 1” Parallel Keyed
Mount: SAE B 2 & 4 Bolt | SAE C 4 Bolt
Shaft: SAE C 1 ¼” 14T Spline
SAE C 1 ¼” Parallel Keyed
Mount: SAE B 2 & 4 Bolt
SAE C 2 & 4 Bolt
