Continuous Pressure Up To: 248 Bar
Thru-Shaft Capability
Customisable Options
Maximum Outlet Pressure: 3600 PSI
| MODEL SERIES | CC/REV | PUMP DELIVERY | INPUT POWER | mAX. sPEED (RPM) | OUTPUT POWER |
|---|---|---|---|---|---|
| PVP16 | 16.0 | 29.5 | 13.1 | 3000 | 248 |
| PVP23 | 23.0 | 42.0 | 19.7 | 3000 | 248 |
| PVP33 | 33.0 | 59.0 | 27.2 | 3000 | 248 |
| PVP41 | 41.0 | 73.8 | 33.2 | 3000 | 248 |
| PVP48 | 48.0 | 86.4 | 40.3 | 3000 | 248 |
| PART NUMBER | ACCESSORIES – DESCRIPTION |
|---|---|
| SKPVP1612 | Seal Kit PVP16 (Suits 12 & 13) |
| SKPVP23/3320 | Seal Kit PVP23/33 |
| SKPVP41/4811 | Seal Kit PVP41/48 |
| Brand |
|---|
Parker PAVC Pump Catalogue PDF
Maximum Displacement From: 33 – 100 cc/rev
2 Bolt SAE Mount/Port Connection
Maximum Flow Rate: 260 LPM/69 GPM
Flange & Straight Threaded Side & Rear Ports
Continuous Pressure Up To: 320 Bar
Thru-Shaft Capability
Adjustable Maximum Volume Stop
Displacements From: 60 – 145 cc/rev
Maximum Outlet Pressure: 5000 psi
Denison Premier Piston Pump PDF
Max. Displacement: 260 cc/rev
Max. Flow : 548 LPM
Operating Pressure: 420 Bar/6000 PSI
Mount & Shaft Type: SAE, ISO, DIN
Port Type: Flange, Opposing, SAE, ISO
